This vacuum pump is suitable for large, heavy packages, and ONLY for non-oily, non-powdery fillings. It is perfect for green (un-roasted) coffee, and is what we use (and highly recommend) to vacuum-pack green coffee at origin. The machine comes with a vertical, stainless steel, retractable nozzle. The air control is operated from a foot switch and is very easy to operate. We have made a video showing how the machine is operated, available to view on You tube, : (.)
The machine requires an outside compressor of 6-7kg/cm2 (at least 3 HP) that you should buy locally, for servicing needs. The gas flush/purge is an optional feature.
We also carry 15 kilo (33 lbs) and 30 kilo (66 lbs) plastic, heavy-duty bags for creating vacuum-packed coffee "bricks". Each machine is custom-built in Taiwan to our exact specifications, developed through vacuum-packing green coffee for long term storage since 2005.
The price quoted is FOB factory in Taiwan. Please contact us for a shipping quote. Both air and sea freight quotes are available.
SPECIFICATIONS:
| MODEL | LMV-6010T | LMV-7510T |
| Voltage | AC 220V 1 Phase Power (Watt.) Amp: 20 A Watt.: 7KW | AC 220V 1 Phase Power (Watt.) Amp: 25 A Watt.: 9.2KW |
| Max. sealing: | 600mm ＊ 10mm*2 (24" X 0.4" *2) | 750mm ＊ 10mm*2 (30" X 0.4" *2) |
| Sealing Time | 0.0 - 3.0 Sec. | |
| Vacuum Tim e | 01 - 90 Sec. | |
| Cooling Time | 0 - 10 Sec. | |
| Pump Capacity: | DP- 120 liter/min. 300W | |
| Weight: | Approximately 220 lbs | Approximately 260 lbs |
| Pump: | Dry Packing (no liquid, no powder) | |
| Dimensions: | 750*600*1620mm (30" X 24" X 65") | 900*600*1620mm (36" X 24" X 65") |
| Compressor needed: | 6-7 KGS/cm2 | |
| Material Used: | Thick Aluminum. Foil Bag, Nylon Bag, Gusseted bag | |
| Sealing Height: | 700 ~ 1100mm (28" ~ 43") (from ground) | |
| Air Tube | 5 ＊ 8 PU Tube | |
| Vacuum Tube | 6.5 ＊ 10 PU Tube | |
| Vacuum Nozzle | 150 ( round)- 150 ( flat) * 1pc | 150 ( round)- 150 ( flat)＊ 2 pc |
| Capacity: | 120L/min | |
| Other: | Electrostatic painted body; the height of head parts can be adjusted. | |
